Drawstring clip for edge 437433

attaching the tightening tape to the edge, attaching the tape horizontally to the edge
More about the product
We will help you with your purchase
Drawstring clip for edge 437433

Drawstring clip for edge 437433

  • Attaching the tape horizontally with the edge
  • Running the cable harness perpendicularly above the edge
  • Max. tape width: 4.8 mm
  • Material thickness for attachment: 0.7 - 3.0 mm
  • Material: polyamide (PA) 6.6 HS
  • Load capacity: max. 200N
  • Working temperature: -10°C - +105°C (°C short-term)
  • Black colour
  • Flammability conforms to UL 94V-2

Methods of use

Easy and quick attachment of a cable harness, hose or pipe to an edge with a thickness of 0.7 - 3 mm. Suitable for the automotive industry, engineering, wiring cabinets and switchboards, office machines, etc.
Catalog number437433
