Hifonics ZXE10S4 subwoofer

Hifonics ZXE10S4 subwoofer

At the heart of the HiFonics ZEUS EVOLUTION woofer drive are powerful Y35 magnets with a diameter of 140 mm, which drive large 64 mm voice coils. These are vented through thermally sensitive pole core bores. In addition, the so-called "bumped" T-plates (pole plates) ensure an even longer stroke, which reaches up to +/- 17 mm (X-Max). While molded diaphragms are usually used in inexpensive woofers, the ZXE subwoofers rely on expensive, hand-made paper diaphragms that are double-stitched to the hinge and are known for their particularly good sound. All these ingredients give the ZXE subwoofers an extremely good efficiency level of 92 or 90 dB at 2.83 volts/1 m, so even with low power consumption the bass can handle high volumes. The Thiele-Small parameters are designed so that the ZXE woofers can be used to build powerful bass reflex boxes with decent depth as well as medium-sized, closed enclosures. Free-Air application is even possible. The Zeus subwoofers also match the HF style in terms of appearance: the newly machined gasket, the HiFonics blue magnetic boot and the blue stitched seam around the diaphragm proudly display the HiFonics brand insignia.

Main features

• 250 mm (10") subwoofer.
• 40 oz (1.14 kg) magnetic drive.
• 64 mm voice coil with X-Max. +/- 16 mm.
• Handmade paper membrane with surface treatment.
• Double stitched membrane.
• Foam curtain.
• Robust steel basket.
• Injected PP dust cap.
• Blue magnet protector.

Catalog number	ZXE10S4
Brand	Hifonics
Links	Official web presentation
